Danfoss 084B4082 Danfoss AK-CC55 Single Coil Case Controller

Product Description

The Danfoss AK-CC55 Single Coil Case Controller, MPN 084B4082, is built for managing single-coil refrigeration systems. It operates effectively with CO2-compliant applications and provides robust control over evaporators and room conditions. The controller ensures compatibility with AKV valves, includes five relays, and supports MODBUS communication with an optional LON interface.

• Designed for single-coil refrigeration systems.
• Supports MODBUS communication with optional LON.
• Compatible with AKV valves and features five relays.

Product Highlights

This controller processes signals from various temperature sensors, like NTC 5000, PTC 1000, and Pt 1000. It also supports a ratiometric pressure transmitter. The unit is suitable for DIN rail mounting, making it a practical choice for various installations.

Product Information

Standard Information

• Application Area: Refrigeration control
• Controller Type: Case Controller Single Coil

Technical Specifications

• Valve Output Type: AKV
• Communication Type: MODBUS
• Communication Card Option: LON RS485
• Number of Evaporators Max.: 1
• Supply Voltage: 115 V / 230 V AC
• Frequency: 50/60 Hz
• Power Consumption: 5 VA
• Digital Inputs (DI): 3
• Digital Outputs (DO): 6
• Analog Inputs (AI): 6
• Analog Outputs (AO): 1
• Temperature Sensor Support: NTC 5000, PTC 1000, Pt 1000
• Pressure Transmitter Support: RATIOMETRIC
• Display: LED 3 digit
• Display on Front: No
• Mounting Type: DIN rail
• Enclosure Rating IP: IP20
• Operating Temperature: 0 to 55 °C
• Approvals: C-TICK, CE
• Net Weight: 325 grams
• Gross Weight: 490 grams
• Product Group: Evaporator and room control
• Sensor Connection: Screw terminals
• Ambient Temperature Range, Transport: -40 to 70 °C
• Relative Humidity Range: 20 to 80%, non-condensing
