Product Description
The Tekmar 360 Mixing Control offers precise and efficient mixing capabilities. This model features a floating action design that automatically adjusts to changing conditions, ensuring optimal mixing performance. It is equipped with an outdoor sensor to accurately monitor outdoor temperatures and two universal sensors for versatile temperature sensing applications.
- Floating action design for precise mixing
- Outdoor sensor for temperature monitoring
- Two universal sensors for enhanced versatility
Product Highlights
The Tekmar 360 Mixing Control is designed to improve mixing efficiency and accuracy. It helps reduce energy consumption and extends equipment life by monitoring and adjusting mixing conditions. This model replaces multiple devices, simplifying system design.
Product Information
Standard Information
Technical Specifications
-
Item Number: 360
-
Packaged Weight: 3.1 lb.
-
Dimensions: 6-5/8 H x 7-9/16 W x 2-13/16 D inches
-
Ambient Conditions: Indoor use only, 32 to 102+F, < 90% RH non-condensing
-
Power Supply: 120 V +10% 50/60 Hz 1300 VA
-
Floating Output: 24 V (ac) 0.34 A 8 VA
-
Relays: 240 V (ac) 10 A 1/3 hp, pilot duty 240 VA
-
Sensors Included: NTC thermistor, 10 k @ 77+F (25+C +0.2+C), 1 Outdoor Sensor 070, 2 Universal Sensor 071
