Checkers bb5x-125-t-b/y 5-channel Cable Protector

Product Description

The CHECKERS bb5x-125-t-b/y is a T-connector cross section designed for use with the Bumble Bee 5-channel light-duty cable protector system. This component creates a T-shaped junction in a modular cable protector layout, allowing hose lines and electrical cables to branch at a 90-degree intersection without breaking the protected run. Built from all-weather polyurethane, it is suited for outdoor and indoor installations where ground-level cable and hose management is required. The diamond plate tread surface provides traction underfoot and under tire in high-traffic crossing zones. Electricians, event production crews, and utility service techs are the primary installers.

This T-connector cross section is used wherever a 5-channel Bumble Bee cable protector run requires a branch point — such as entertainment venues, outdoor events, utility worksites, and light industrial setups. The modular interlocking design connects directly to compatible Bumble Bee 5-channel straight sections and end caps, allowing the layout to be expanded or reconfigured as site conditions change. The hinged-lid design on the base system allows cable access without disassembling the run.

Key Features

• T-connector cross section creates branch points in a 5-channel cable protector layout
• All-weather polyurethane construction handles outdoor exposure without degrading
• Diamond plate tread surface maximizes traction for pedestrian and vehicle traffic
• Modular interlocking design integrates with other Bumble Bee 5-channel components
• Protects electrical cables and hose lines from damage in high-volume traffic areas
• Suited for light entertainment and utility applications

Compatibility

Designed for use with the Bumble Bee 5-channel light-duty cable protector system with hinged lid. Compatible with other Bumble Bee 5-channel modular components including straight sections, end caps, and connectors.

Installation Notes

Installation is typically performed by electricians or event production technicians setting up ground-level cable management runs. Position the T-connector at the branch point before routing cables through the channels, and ensure all cables and hose lines are de-energized or depressurized before feeding them through the protector. Interlock the modular sections firmly to prevent shifting under traffic load. Follow applicable NEC guidelines when routing energized electrical conductors through cable management systems.

Technical Specifications

• Channels: 5
• Material: All-weather polyurethane
• Tread Surface: Diamond plate
• Configuration: T-connector cross section
• Duty Rating: Light-duty

Standard Information

• Brand: CHECKERS
• Manufacturer Part Number: bb5x-125-t-b/y
