Bessey 375L Adjustable Self-positioning Strap Clamp Steel

Product Description

The BESSEY 375L is an adjustable self-positioning strap clamp designed for securing workpieces during machining, fabrication, and fixture setups. Built from steel with a 0.375 inch stud diameter, this strap clamp accommodates a maximum clamping height of 1.25 inches. The self-positioning design allows the strap to automatically level and seat flush against uneven or stepped surfaces without manual shimming. With a rated load capacity of 7,000 pounds, it delivers reliable holding force for demanding production and toolroom environments. Machinists, tool and die makers, and fabricators install these clamps as part of workholding setups on milling machines, drill presses, and surface grinders.

The 375L is suited for light-duty to medium-duty workholding applications in job shops, production machining cells, and fabrication environments. Its compact profile measuring 3.75 inches long, 1.125 inches wide, and 1.25 inches high makes it well-suited for setups where clearance is limited. The adjustable strap design accommodates varying workpiece heights within the rated clamping range, reducing setup time when transitioning between parts of different thicknesses.

Key Features

• Self-positioning strap automatically seats against workpiece surfaces for consistent clamping force
• 7,000 pound load capacity for secure workholding in machining and fabrication applications
• 0.375 inch stud diameter compatible with standard T-slot and fixture plate hardware
• Steel construction for durability under repeated use and exposure to cutting fluids
• Compact dimensions of 3.75 inches long by 1.125 inches wide by 1.25 inches high for tight setups
• Maximum clamping height of 1.25 inches suits thin-profile workpieces and fixture components

Compatibility

Designed as an OEM-style workholding strap clamp for use with standard 0.375 inch stud hardware in T-slot tables, fixture plates, and modular workholding systems.

Installation Notes

Installation is performed by machinists or toolroom technicians familiar with workholding setups. Ensure the machine table or fixture plate is free of chips and coolant residue before seating the clamp. Torque the stud nut evenly and verify the strap is fully seated before initiating any machining operation. Always confirm the workpiece is properly supported and the clamp is positioned over a solid bearing point to prevent part movement under load.
