Belimo B232+AFRB24 CCV 1.25 2 Way 37 Cv Spg Rtn 24V On/Off

Product Description

The Belimo B232+AFRB24 CCV is a 1.25-inch, 2-way valve with a 37 Cv capable of on/off control. It's designed for use in air handling units on heating or cooling coils and fan coil unit heating or cooling coils. Common applications include unit ventilators, VAV box re-heat coils, and bypass loops. This valve is suitable for hydronic systems with variable flow.

• 1.25-inch valve size
• 2-way pattern
• 24V on/off control

Product Highlights

Designed for various HVAC applications, the Belimo B232+AFRB24 provides efficient and reliable on/off control for hydronic systems.

Product Information

Standard Information

• Brand: Belimo
• MPN: B232+AFRB24
• Category: Ball Valves
• Product Type: Valve

Technical Specifications

• Valve specifications:
• Angle of Rotation: 90
• Controllable Flow Range: 75B0
• Cv: 37
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60 percent glycol
• Pattern: 2-way
• Pressure Independent: NO
• Trim: Stainless steel
• Valve Size: 1.25 (32)
• Actuator specifications:
• Actuator Type: Spring return
• Control Type: On/Off
• Degree of Protection: IP54 NEMA 2 UL Enclosure Type 2
• Electrical Connection: Cable
• Manual Override: 5 mm hex crank (3/16 Allen) supplied
• Power Consumption (Holding): 2.5 W
• Power Consumption (Running): 5 W
• Running Time (Fail-safe): less than 20 seconds
• Running Time (Motor): 75 seconds per 90B0
• Voltage AC/DC: AC/DC 24V
