Product Description
The Belimo B209+LRB24-SR is a two-way 0.5 inch valve with a 0.8 Cv and non-spring return. This valve is designed for efficient control in hydronic systems with variable flow. It operates at 24V with a DC 2 to 10 V control type.
- Two-way valve with 0.8 Cv
- Operates at 24V
- Non-spring return
Product Highlights
Designed for use in air handling units and fan coil units, the Belimo B209+LRB24-SR ensures precise control of heating and cooling. It is suited for hydronic systems in various applications such as unit ventilators and VAV box re-heat coils.
Product Information
Standard Information
-
Manufacturer: Belimo
-
Model: B209+LRB24-SR
-
Type: Two-way valve
Technical Specifications
-
Cv: 0.8
-
Valve Size: 0.5 inches
-
End Fitting: Internal thread
-
Fluid: Chilled or hot water up to 60% glycol
-
Pattern: 2-way
-
Angle of Rotation: 90 degrees
-
Actuator Type: Non fail-safe
-
Control Type: DC 2...10 V
-
Degree of Protection: IP54 NEMA 2 UL Enclosure Type 2
-
Electrical Connection: Cable
-
Manual Override: External push button
-
Power Consumption (Holding): 0.4 W
-
Power Consumption (Running): 1.5 W
-
Running Time (Motor): 90 s / 90 degrees
-
Voltage AC/DC: AC/DC 24 V
