Belimo B207B Characterized Control Valve 1/2 Inch 2-Way 0.3Cv

Product Description

The Belimo B207B is a precision-engineered characterized control valve designed for regulating flow in HVAC systems. This valve facilitates reliable and efficient flow control within commercial heating and cooling systems.

• Optimized for low-flow applications with a controllable flow range specification.
• Features a robust chrome plated brass trim for extended service life.
• Effortlessly integrates into both hot and chilled water systems up to 60% glycol.

Product Highlights

The B207B valve is notable for its compact half-inch size and two-way internal thread design, making it ideal for installation in limited spaces.

Product Information

Standard Information

• Brand: Belimo
• Model: B207B
• Type: 2-Way CCV

Technical Specifications

• Valve Size: 0.5 inches
• Pattern: 2-way
• Flow Coefficient (Cv): 0.3
• End Fitting: Internal thread
• Material: Chrome plated brass
• Fluid Compatibility: Chilled or hot water up to 60% glycol
• Pressure Independent: No
