Ay Mcdonald 5050ctsjpac simplex sewage package 1/2 hp

Product Description

The AY MCDONALD 5050CTSJPAC pre-assembled simplex sewage package is designed for residential sewage applications. It features a 30-gallon capacity and 2" solids handling. The 2" discharge pipe is connected to the sewage pump, making it ready for installation. A split lid allows easy access to the pump without disturbing the discharge pipe.

• Includes (5050CTSJ) 1/2 HP Cast iron sewage ejector
• Features a durable structural foam sewage basin with 4" inlet
• Comes with a 2" full flow check valve with rubber boots

Product Highlights

This simplex sewage package is pre-assembled and designed for residential sewage applications. It offers easy installation and access for maintenance.

Product Information

Standard Information

• Brand: AY MCDONALD
• Manufacturer Part Number: 5050CTSJPAC

Technical Specifications

• Model: 5050CTSJPAC
• HP: 1/2
• Volts: 120
• Hz: 60
• Amps: 7.6
• Construction: Cast Iron
• Discharge Size: 2"
• Cord Length: 10'
• Solids Handling: 2"
• RPM: 3450
• Phase: 1
• Part No.: 6192-115
• Wt.: 54
• MOTOR TYPE: Split Capacitor
• MAXIMUM HEAD: 25'
• MAXIMUM CAPACITY: 80 GPM
• SWITCH TYPE: Tethered Float Switch
• IMPELLER TYPE: Non-Clogging, Stainless Steel Vortex
• MAXIMUM LIQUID TEMPERATURE: 120°F (49°C)
• DUTY RATING: Continuous
