Accupro 00199604 Solid Carbide Split-end Blank 0.25in 60deg

Product Description

The ACCUPRO 00199604 is a solid carbide split-end blank designed for precision tooling applications requiring a single-end, conical point geometry. Built from solid carbide throughout, this blank delivers the rigidity and wear resistance needed for high-accuracy machining environments. The conical point is ground to a 60-degree angle, making it suitable for use as a center drill blank or specialized point-form tool. With an overall length of 2.5 inches and a split length of 0.375 inches, it provides a compact, stable platform for secondary grinding or direct use in light-duty center-finding operations. Machinists and toolroom professionals are the primary users of this blank.

This split-end blank is used in toolroom, production machining, and tool-grinding environments where a pre-formed carbide blank with a defined conical point is required. It is suited for applications in CNC machining centers, manual mills, and grinding setups where the operator needs a consistent starting geometry before finish-grinding to a final tool profile. The 60-degree single conical point style reduces regrinding time by providing a near-finished point form from the start.

Key Features

• Solid carbide construction for high wear resistance and rigidity
• 60-degree conical point angle for precise center-finding and point-form applications
• Single-end configuration with a 0.375-inch split length
• 0.25-inch diameter body suited to compact tooling setups
• 2.5-inch overall length provides stable tool-holding in standard collets and chucks

Compatibility

Designed as an OEM-style solid carbide blank for use in standard 0.25-inch collets, chucks, and tool-holding systems compatible with split-end blank configurations.

Installation Notes

Installation and setup of carbide blanks should be performed by a qualified machinist or toolroom technician. Secure the blank in a properly sized collet or chuck before use, ensuring full engagement along the shank. Carbide is brittle and should not be subjected to impact loading or side forces beyond its rated geometry. Inspect the blank for chips or cracks before mounting.
