ABB 2RB14 Nylon-Insulated Butt Splice - #16-14

Product Description

ABB 2RB14 is a nylon-insulated butt splice connector designed for wire connections in the size range of #16 to #14 AWG. This product provides a reliable method for connecting wires while ensuring insulation integrity. It measures 1.19 inches in length and features a maximum insulation diameter of 0.148 inches.

• Insulated to meet MIL-T-7928 standards
• Suitable for use with copper conductors
• Color-coded for easy wire size identification

Product Highlights

This connector is ideal for electrical applications where secure wire connections are essential.

Product Information

Standard Information

• Brand: ABB
• Manufacturer: Thomas & Betts Co

Technical Specifications

• Type: Nylon Insulated Butt Splice
• Color: Blue
• Material: Copper
• Finish: Electro-Tin Plated
• Voltage Rating: 600 VAC
• Temperature Rating: 105 degrees C
• Conductor Size: 16 to 14 AWG
• Dimensions: 1.19 in Length, 0.21 in Width
• Maximum Insulation Diameter: 0.148 in
