3M UF2 Underground Feeder Splice Kit 600V (1 Kit) UF2-SPLICE-KIT

Product Description

3M UF2 is an underground feeder splice kit designed for Type UF-B cables and rated for 600 V. The kit provides a moisture-resistant, adhesive-lined heat shrink insulator and a cylindrical set-screw terminal connector to join copper conductors sized 14 to 8 AWG. It includes an 11.7 inch terminal connector and a 20 inch heavy-wall heat shrink tube, and carries UL approval and RoHS compliance with an operating range of -67 to 230�F.

• 600 V rating for Type UF-B underground feeder (copper only); supports #14/3 without ground up to #8/3 with ground
• Cylindrical set-screw connector with adhesive-lined heavy-wall heat shrink tube (11.7 in connector; 20 in tube)
• Certifications: UL listed heat-shrink; RoHS compliant; operating temperature -67 to 230�F

Product Highlights

Underground feeder splice kit for copper UF-B cable, 600 V rated, supports 14�8 AWG, includes 11.7 in connector and 20 in adhesive-lined heat-shrink tube; UL and RoHS certified.

Product Information

Standard Information

• Brand: 3M
• Manufacturer Part Number: UF2
• Country of Origin: Taiwan

Technical Specifications

• Brand: 3M
• Manufacturer Part Number: UF2
• Alternate Part Number: UF2-SPLICE-KIT
• Product Name: Underground feeder splice kit
• Voltage Rating: 600 V
• Cable Type: Type UF-B underground feeder (flat, non-shielded, copper only)
• Supported Conductor Size: 14 to 8 AWG; #14/3 without ground up to #8/3 with ground
• Number of Conductors: 1 (single-conductor splice)
• Connector Type: Cylindrical set-screw terminal
• Insulator Type: Adhesive-lined heat shrink
• Contents: 11.7 inch terminal connector; 20 inch heavy-wall adhesive-lined heat shrink tube; connector insulation assembly
• Certifications: UL listed; RoHS compliant
• Operating Temperature: -67 to 230 6F (-55 to 110 6C)
• Application Temperature: 0 to 120 6F
• Country of Origin: Taiwan
• Unit Weight: 0.625 lb
• Package Quantity: 6 kits per case
• Package Weight: 4.205 lb
• GTIN: 00054007429210
• UPC: 054007429210
