Honeywell M6410A1029 Cartridge Globe Spring Return Valve Actuator - 24V SPDT

Product Description

The Honeywell M6410A1029 Cartridge Globe Valve Actuator is designed to control the flow of media in HVAC systems. It operates on 24V and uses a single-pole, double-throw (SPDT) switch. This actuator provides floating or modulating control of V5852, V5862 two-way or V5853, V5863 three-way valves, making it suitable for a variety of heating, ventilation, and air conditioning applications.

• Compatible with V5852, V5862, V5853, and V5863 valves
• Operates with 24V power
• Provides a floating control signal

Product Highlights

This actuator is designed for use in rooms or spaces that require precise control of temperature and air flow. It includes features such as a magnetic coupling to limit torque, visual position indication, and it does not require mounting tools.

Product Information

Standard Information

• Application: Electronic Temperature Control Systems
• Body Material: Brass

Technical Specifications

• Type: Cartridge Globe
• Stroke: 1/4 in
• Timing: 125 s
• Includes: 1/2 in Conduit Hub
• Signal Type: 2 Position/Floating/SPDT
• Mounting Type: Valve Body
• Temperature Rating: 32 to 122 deg F
• Power Consumption: 0.7 VA
