Johnson Controls M9220-GGA-3 Direct Coupled 177 lb-in Spring Return

Product Description

The Johnson Controls M9220-GGA-3 is a direct coupled actuator designed to provide precise control in various HVAC applications. It operates at 24 VAC with a power consumption of 25 VA, making it efficient for managing dampers and valves. The actuator features a spring return mechanism, providing reliable operation while requiring minimal maintenance.

• Reversible mounting design for flexible installations
• Electronic stall detection enhances actuator lifespan
• Locking manual override allows for easy manual positioning

Product Highlights

The actuator is built to accommodate different shaft sizes and offers a compact design ideal for tight spaces.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: M9220-GGA-3

Technical Specifications

• Torque: 177 lb-in
• Power Consumption: 15.5 VA running, 7.7 VA holding
• Operating Conditions: -40 F to 131 F (-40 C to 55 C)
• Electrical Connection: 48 in. 18 AWG wire leads with integral connectors
• Fail Safe Mode: Spring return
• Housing: NEMA 2, IP54
