Johnson Controls M9208-GGA-2 Electric Actuator 24V 70 lb-in

Product Description

The Johnson Controls M9208-GGA-2 Electric Actuator is a robust device designed to control dampers in HVAC systems with a torque rating of 70 lb-in. This actuator features a direct coupling mechanism, eliminating the need for damper linkage.

• Engineered for direct mounting allowing straightforward installations.
• Features a mechanical spring-return system ensuring reliable operation by providing rated torque with or without power.
• Equipped with electronic stall detection to prevent damage during operation.
>

Product Highlights

Optimal design for HVAC systems where precise control of damper positions is required. It fits damper shafts from 5/16 inches to 5/8 inches in diameter directly, and up to 3/4 inches with an accessory kit.

Product Information

Standard Information

• Brand: Johnson Controls
• Model: M9209-GGA-2

Technical Specifications

• Torque: 70 lb-in
• Voltage: 24V
• Operating Temperature Range: -40 to 140°F
• Material: Double-insulated construction
• Mounting Type: Direct, with optional clamp for larger shafts
