Sealed Unit Parts Co SUPCO-FLS201 Flame Sensor

Product Description

The Sealed Unit Parts Co SUPCO-FLS201 Flame Sensor is essential for safe and efficient heating system operation. This flame sensor is suitable for both hot surface ignition (HSI) and direct spark ignition systems. It features an alumina ceramic insulator and a Kanthal flame rod, ensuring durable performance in high-temperature environments.

• Utilizes alumina ceramic insulator and Kanthal flame rod for high-temperature resistance.
• Compatible with HSI and direct spark ignition systems.
• Detects flame presence to ensure safety and efficiency.

Product Highlights

The SUPCO-FLS201 contributes to optimal combustion by providing a reliable flame signal. It also responds quickly to flame loss, helping prevent overheating and reduce energy use.

Product Information

Standard Information

• Product Type: Flame Sensor
• Gas Type: Liquid Propane, Natural Gas

Technical Specifications

• Flame Rod Material: Kanthal
• Insulator Material: Alumina Ceramic
• Temperature Withstand: 1800 Degrees Fahrenheit
• Length: 2.00 inches
• Termination: 1/4 Inch Quick Connect
• Probe Length: 3 inches
• Height: 1/2 inch
• Igniter Warm-up Time: 17 seconds
