Rcd p291-2504 Run Capacitor 25 Mfd 440V Oval Hvac

Product Description

The RCD p291-2504 is a single run capacitor rated at 25 microfarads (MFD) and 440 volts AC, designed as an OEM-style replacement for residential and light commercial HVAC equipment. Run capacitors maintain the phase shift in motor windings to keep compressor and fan motors running at rated efficiency. This oval-profile unit is built with an aluminum case and quick-connect terminals, making field replacement straightforward. Licensed HVAC technicians install this part during routine service calls and compressor or condenser fan motor replacement jobs.

This capacitor is suited for single-capacitor applications in split-system air conditioners, heat pumps, and packaged HVAC units where the original specification calls for a 25 MFD, 440-volt single run capacitor. Per the supplier data, this part fits the 48HJD015-600, 48HJD015-500, and 48HJD015-100 series units, among others. Its 50/60 Hz rating covers standard North American electrical systems. The oval form factor fits standard capacitor brackets found in most condenser and air handler cabinets.

Key Features

• 25 MFD capacitance with a tight tolerance of plus or minus 6 percent for consistent motor performance
• 440-volt AC rating provides voltage headroom above standard 208/240-volt systems
• Oval aluminum case fits standard capacitor mounting brackets
• Quick-connect terminals allow fast, tool-free wire attachment
• Rated for 50/60 Hz operation, compatible with standard North American supply frequency
• Temperature rating of -29 to 68 degrees C supports wide operating environments

Compatibility

Compatible with 48HJD015-600, 48HJD015-500, and 48HJD015-100 series units, as well as other equipment specifying a single 25 MFD, 440-volt oval run capacitor.

Installation Notes

Run capacitor replacement is a task for a licensed HVAC technician. Disconnect and lock out all power to the unit before accessing the capacitor compartment — capacitors can hold a dangerous charge even after power is removed, and must be safely discharged before handling. Verify the replacement capacitor matches the original MFD rating and voltage rating before installation. Consult local codes and the equipment manufacturer service manual for any additional requirements.

Technical Specifications

• Capacitance: 25 MFD
• Voltage: 440 volts AC
• Frequency: 50/60 Hz
• Type: Run
• Configuration: Single
• Tolerance: plus or minus 6 percent
• Terminal Type: Quick Connect
• Shape: Oval
• Material: Aluminum
• Temperature Rating: -29 to 68 degrees C
• Length: 4.3 inches
• Width: 3.15 inches
• Height: 2.25 inches

Standard Information

• Brand: RCD
• Manufacturer Part Number: p291-2504
