Rcd m7415a1006 Motor Damper Actuator 24 Vac

Product Description

The RCD m7415a1006 is a motor damper actuator designed for use in HVAC air distribution systems where automated damper control is required. Operating on 24 VAC at 50/60 Hz, this actuator drives damper blades to regulate airflow in ductwork, air handling units, and ventilation systems. It features counter-clockwise (CCW) shaft rotation and a foot-mounted configuration for straightforward mechanical installation. Thermal protection is built in, guarding the motor against overload conditions. Weighing 11.95 pounds and measuring 4.8 inches in length, 4.5 inches in width, and 4.7 inches in height, it is a compact, single-speed unit suited for commercial and residential HVAC applications. Installation is typically performed by licensed HVAC technicians as part of a zone control or ventilation system.

The m7415a1006 is applied in HVAC systems where low-voltage actuator-driven dampers manage zone airflow or outside air intake. Common installation scenarios include rooftop units, air handlers, and ducted zone control systems requiring a reliable 24 VAC damper motor. The foot-mounted design allows secure attachment to damper frames or duct assemblies. This actuator is manufactured in Mexico and carries CSA Listed approval, confirming compliance with recognized safety standards for electromechanical HVAC components.

Key Features

• 24 VAC operating voltage compatible with standard low-voltage HVAC control circuits
• Counter-clockwise (CCW) rotation for correct damper blade actuation
• Foot-mounted design for secure mechanical attachment to damper assemblies
• Built-in thermal protection to prevent motor burnout under overload conditions
• CSA Listed for safety compliance in commercial and residential HVAC installations
• Single-speed operation, 50/60 Hz compatible

Compatibility

Designed as an OEM-style replacement motor damper actuator for 24 VAC low-voltage HVAC damper applications requiring a foot-mounted, counter-clockwise rotating actuator.

Installation Notes

Installation should be performed by a qualified HVAC technician. Disconnect and lock out all power to the HVAC system and de-energize the 24 VAC control circuit before removing or installing the actuator. Verify damper shaft rotation direction and mounting orientation before securing the unit. Consult local mechanical codes and the equipment manufacturer documentation for applicable wiring and mounting requirements.

Technical Specifications

• Voltage: 24 VAC
• Cycle/Hertz: 50/60 Hz
• Number of Speeds: 1
• Rotation: Counter Clockwise (CCW)
• Mounting Type: Foot-mounted
• Thermal Protection: Yes
• Length: 4.8 inches
• Width: 4.5 inches
• Height: 4.7 inches
• Weight: 11.95 pounds
• Approvals: CSA Listed
• Country of Origin: Mexico

Standard Information

• Brand: RCD
• Manufacturer Part Number: m7415a1006
