Abb Installation Products Rc10-8 Sta-Kon® Rc10-8 Terminal Ring #8

Product Description

The ABB INSTALLATION PRODUCTS RC10-8 Sta-Kon® Ring Terminal is an insulated terminal from the RC Series, designed for 12 to 10 AWG conductors and a #8 stud. Constructed from copper with tin coating, it ensures high conductivity and corrosion resistance. It features an insulation grip sleeve barrel and a ring tongue, suitable for up to 600 VAC and temperatures up to 105 deg C.

• Self-insulated with high dielectric strength nylon sleeves
• Inner bronze insulation grip sleeve lengthens the flexing radius of the conductor and eliminates conductor creep
• Made of copper and has electro-tin plating for high conductivity/corrosion resistance

Product Highlights

The Sta-Kon® RC10-8 ring terminal provides a secure and durable connection for electrical applications, featuring robust construction and reliable insulation.

Product Information

Standard Information

• Brand: ABB INSTALLATION PRODUCTS
• Manufacturer Part Number: RC10-8
• Country of Origin: United States

Technical Specifications

• Manufacturer: ABB - Installation Products
• Barrel Type: Insulation Grip Sleeve
• Conductor Size: 12 to 10 AWG
• Length: 1 in
• Type: Insulated
• Series: RC Series
• Stud Size: #8
• Tongue Type: Ring
• Tongue Size: 0.37 in W x 0.04 in THK
• Voltage Rating: 600 VAC
• Specifications: 0.21 in Dia Maximum Insulation, 0.27 in Clearance, Nylon Insulation
• Temperature Rating: 105 deg C
• Finish: Tin Coated
