YORK S1-THSU303-S Programmable Thermostat with Humidity Control

Product Description

The York S1-THSU303-S is a programmable thermostat ideal for residential settings. With its seven-day programming feature, users can customize the temperature settings for each day of the week. This thermostat effectively manages up to three stages of heating and two stages of cooling. It also includes humidity control, equipped with outputs for both humidification and dehumidification systems.

• Seven-day programmable thermostat
• Supports three heating and two cooling stages
• Features humidity control outputs

Product Highlights

The York S1-THSU303-S helps maintain a comfortable indoor climate through precise temperature and humidity management.

Product Information

Standard Information

• Manufacturer: York
• Part Number: S1-THSU303-S

Technical Specifications

• Power Requirements: 20 - 30 VAC 50/60 Hz, 3.0 VA @ 24V nominal
• Output Rating W1, W2, W3: 0.2A max, 0.01A min, 3A inrush, 20 - 30 VAC
• Output Rating Y1, Y2, G: 0.4A max, 0.01A min, 3A inrush, 20 - 30 VAC
• Output Rating HUM, DEHUM, AUX: 0.1A max, 0.01A min, 3A inrush, 20 - 30 VAC
• Dimension: 4.4 inches high x 5.2 inches wide x 1 inch deep
