YORK S1-CSDECM-C35200L0 Current Switch

Product Description

The YORK S1-CSDECM-C35200L0 is a current switch designed specifically for electronically commutated motors (ECMs). This device features a split-core design, simplifying the installation process as it can be fitted without the need to disconnect the conductor. The current switch serves as a reliable method for confirming the operation of electrical equipment and can also function with various electrical loads where a simple sensor is required. It operates with a normally open (N.O.) output.

• Split-core design allows for easy installation
• Fixed trip point at 0.35 amperes minimum turn-on
• Normally Open (N.O.) contact type for reliable operation

Product Highlights

This current switch provides essential monitoring capabilities for ECMs and other electrical systems, ensuring safety and operational efficiency.

Product Information

Standard Information

• Country of Origin: United States

Technical Specifications

• Current Amperage Range: 0.35 to 200 Amps
• Current Contact Type: Normally Open
• Current Core Type: Split-Core
• Current Trip Point Type: Fixed Trip Point
• Current Type: Current Switch
• Minimum Turn-On Amps: 0.35
• Maximum Amps: 200
• Contact Rating: 10 Amps at 125 VAC
• Switch Load Capacity: 1.0 at 30 VAC/VDC
• Switch Setpoint: Fixed
• Status Output: Switch normally open
• Frequency Range: 50/60 Hz
• Isolation Voltage: 600 VAC rms (UL), 300 VAC rms (CE)
