York CM48DBCA1 Add-On Indoor Coil 4 ton CM48DBCA1

Product Description

The York CM48DBCA1 is an add-on indoor coil designed for use with UPG furnaces or modular air handlers in matched air conditioning systems. It provides efficient cooling and heating capabilities in residential and commercial applications.

• Multi-position installation options for flexible setup
• Durable construction with galvanized steel for corrosion resistance
• Engineered for efficient refrigerant flow with factory-installed TXV technology

Product Highlights

Capable of handling a nominal capacity of four tons, the York CM48DBCA1 is suitable for split-system cooling and heat pump applications. It is designed using MaxAlloy aluminum coils for enhanced performance and efficiency.

Product Information

Standard Information

• Brand: York
• Part Number: CM48DBCA1

Technical Specifications

• Air Flow Direction: Multi-Position
• CFM Rating: 1600 cfm
• Coil Rating: 8.55 sq-ft Face Area, 2 Rows, 14 fins/in
• Coil Size: (3) 24 x 17.1 inches
• Connection Type: 3/8 inches Sweat Liquid, 7/8 inches Sweat Vapor
• Dimensions: 24-1/2 inches W x 32-3/4 inches H x 21-1/2 inches D
• Finish: Galvanized
• Material: Steel
• Model: CM48D
• Nominal Capacity: 4 ton
• Refrigerant: R-410A, R-22
• Series: CM
• Type: Full-Cased
