YG-1 APKT100305PDTR-YG602 Solid Carbide Milling Insert

Product Description

The YG-1 APKT100305PDTR-YG602 is a solid carbide parallelogram-style milling insert with a TiAlN coating applied via PVD process. It carries the APKT insert style in size code 100305 and is designed for positive-rake face milling operations. The insert measures 0.3937 inches in length and 0.2640 inches in inscribed circle diameter, with a thickness of 0.1420 inches and a corner radius of 0.0197 inches. With a maximum depth of cut of 0.3900 inches and two chamfered and honed cutting edges, it is suited for productive material removal on a range of workpiece materials. Licensed machinists and CNC tooling technicians are the primary installers and users.

This insert is intended for right-hand milling applications in both production and job-shop environments. It is rated for use on steel, stainless steel, cast iron, and superalloys and titanium, corresponding to material grades P20, M20, K20, and S15. Compatible cutter series include the E90-AP and F90-AP face mill bodies. The common chip breaker geometry supports general-purpose milling across this range of workpiece materials. It conforms to both ANSI and ISO standards under the designation APKT100305PDTR-YG602.

Key Features

• Solid carbide substrate with PVD TiAlN coating for heat and wear resistance
• Positive rake geometry reduces cutting forces and tool pressure
• Two chamfered and honed cutting edges per insert
• Right-hand cutting orientation with screw-lock insert holding
• Maximum depth of cut of 0.3900 inches
• Compatible with E90-AP and F90-AP cutter series

Compatibility

Compatible with E90-AP and F90-AP series face mill cutter bodies. Designed for use on steel, stainless steel, cast iron, and superalloys and titanium workpiece materials. Conforms to ANSI and ISO insert standards under code APKT100305PDTR-YG602.

Installation Notes

Installation is performed by a qualified machinist or CNC tooling technician. Power down and lock out the machine spindle before seating or replacing inserts. Secure the insert with the appropriate torx or hex drive screw to the manufacturer seat specification for the cutter body in use. Inspect the insert pocket for debris or damage before seating a new insert to ensure proper contact and runout.
