Xylem 113200 Model FS1 Snap Liquid Flow Switch 120 Volt 1/2 Inch

Product Description

The XYLEM 113200 Model FS1 is a 120 volt, single pole, double throw, snap liquid flow switch designed for high sensitivity requirements in low to moderate flow rates. It is suitable for applications such as air conditioning, heating, and hydronic systems. This switch features a 1/2 inch FIP in-line configuration, a maximum temperature of 225°F, and a 100 psi operating pressure.

• Operates at 120 volts for standard electrical systems.
• Features a single pole, double throw (SPDT) snap switch mechanism.
• Includes a sensitivity adjustment screw for precise flow calibration.

Product Highlights

Ideal for precise liquid flow monitoring in HVAC and hydronic systems.

Product Information

Standard Information

• Brand: XYLEM
• Manufacturer Part Number: 113200

Technical Specifications

• Model: FS1
• Application: Liquid Flow
• Enclosure Rating: NEMA 1
• Input Voltage: 120V, 240V
• Connection Size: 1/2 inch
• Connection Type: NPT female threaded
• Maximum Operating Pressure: 100 psi
• Maximum Operating Temperature: 225°F
• Maximum Velocity: 10 ft/sec
• Minimum Operating Temperature: 32°F
• UPC: 751875000199
• Item Number: MCMFS1
• Frequency: 50/60 Hz
• Manufacturer: Xylem
• Series: FS1
• Amperage: 3.7 to 7.4 A
• Category: Flow Switch
