Wiring Device-Kellems RR330 1-Phase Single Surface Mounted Screw Mount Straight Blade Receptacle

Product Description

The Wiring Device-Kellems RR330 is a straight blade power receptacle designed for 1-phase single surface mounting. It operates at 125/250 VAC and handles a maximum of 30 A with three poles and three wires. This receptacle is suitable for residential applications and is made from thermoplastic material.

• Designed for 1-phase single surface mounting
• Compatible with 125/250 VAC operating voltage
• Meets 10-30R NEMA rating

Product Highlights

Perfect for residential setups, the RR330 is equipped with pressure screw terminals and allows straightforward installation with robust securing features for reliable connections.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• Manufacturer: Hubbell

Technical Specifications

• Type: 1-Phase Single Surface Mounted Screw Mount
• Voltage Rating: 125/250 VAC
• Amperage Rating: 30 A
• Number of Poles: 3
• Number of Wires: 3
• NEMA Rating: 10-30R
• Grade: Residential
• Material: Thermoplastic
• Dimensions: 5.49 in L x 2.5 in W x 0.96 in H
