Wiring Device-Kellems RC109W Standard Sized Combination Toggle Switch 120 VAC 15 A

Product Description

The Wiring Device-Kellems RC109W is a reliable combination toggle switch designed for various electrical applications. It operates at 120 VAC and supports up to 15 A and 1800 W. This switch features an amber neon pilot lamp and a two-position contact configuration, making it suitable for controlling a range of devices in residential and commercial settings.

• Standard sized combination toggle switch
• Voltage rating of 120 VAC and amperage rating of 15 A
• Temperature rating between -20 to 60 degrees Celsius

Product Highlights

This toggle switch is constructed from composite materials, ensuring durability and a long service life. It includes a snap action mechanism for ease of use and a threaded mounting design for secure installation.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• Manufacturer: Hubbell

Technical Specifications

• Action: Snap
• Color: White
• Contact Configuration: 2-Position
• Contact Rating: 15 A
• Dimensions: 1.32 in W x 1.53 in D x 4.2 in H
• Lamp Type: Amber Neon Pilot
• Material: Composite
• Mounting: Threaded
• Number of Poles: 1
• Temperature Rating: -20 to 60 degrees Celsius
• Terminal Type: Side Wire
• Type: Standard Sized
• Voltage Rating: 120 VAC
• Amperage Rating: 15 A
• Wattage: 1800 W
