Wiring Device-Kellems HBL5464VY 1-Phase Grounding Male Portable Standard Cord Mount 6-20P

Product Description

The Hubbell HBL5464VY is a wiring device that serves as a grounding male portable standard cord mount straight blade plug. It is rated for two hundred fifty volts alternating current and twenty amps. This device features two poles and three wires and is designed in a yellow color.

• Designed for easy wiring and assembly
• Impact and crush-resistant construction
• All components fully insulated for safety

Product Highlights

This wiring device is well-suited for use in commercial and industrial applications.

Product Information

Standard Information

• Manufacturer: Hubbell
• Brand: Wiring Device-Kellems

Technical Specifications

• Cord Diameter: 0.22 to 0.66 in
• Dimensions: 1.88 x 1.5 x 1.13 in
• Enclosure: IP20
• Grade: Commercial/Industrial
• Horsepower: 2 hp
• Material: Composite
• NEMA Rating: 6-20P
• Temperature Rating: -40 to 75 deg C
• Terminal Type: Screw
• Voltage Rating: 250 VAC
• Amperage Rating: 20 A
• Number of Poles: 2
• Number of Wires: 3
• Color: Yellow
