Wiring Device-Kellems DR20WHITR - 1-Phase Decorator Duplex Self-Grounding Standard Tamper Resistant Screw Mount

Product Description

Wiring Device-Kellems DR20WHITR is a straight blade receptacle designed for reliable electrical connections. The product operates at 125 VAC and supports a current of up to 20 A. This receptacle features a tamper-resistant design, making it safe for use in various environments. It is constructed from nylon and has a white finish, offering a practical solution for both residential and commercial applications.

• Durable nylon construction
• Self-grounding feature
• Tamper-resistant design for safety

Product Highlights

This receptacle is suitable for standard wiring installations and features side wired terminals for easy connections. It can handle a voltage of 125 VAC and is rated for 20 A with a horsepower of 1. The NEMA rating of 5-20R ensures compatibility with standard plugs.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• Manufacturer: Hubbell

Technical Specifications

• Type: 1-Phase Decorator Duplex Self-Grounding Standard Tamper Resistant Screw Mount
• Dimensions: 3.28 x 1.14 x 1.29 inches
• Grade: Commercial/Specification
• Horsepower: 1 hp
• Material: Nylon
• NEMA Rating: 5-20R
• Temperature Rating: -40 to 75 deg C
• Terminal Type: Side Wired
• Voltage Rating: 125 VAC
• Amperage Rating: 20 A
• Number of Poles: 2
• Number of Wires: 3
• Color: White
