Wiremold PM48T Raceway Power Module 48 Inch

Product Description

The WIREMOLD PM48T is a raceway power module designed to deliver in-wall or surface-mounted power distribution in commercial and light commercial wiring applications. At 48 inches in length, this module integrates into Wiremold raceway systems to provide organized, code-compliant routing of electrical conductors and outlet feeds along walls, columns, or workstation runs. Licensed electricians and low-voltage installers typically specify this unit where surface-mount wiring management is required and in-wall rough-in is not practical. The module measures 4.5 inches wide by 4.5 inches tall by 50.5 inches long and weighs 4.65 pounds.

The PM48T is suited for commercial office buildouts, classrooms, healthcare facilities, and retail environments where accessible power distribution along wall surfaces is standard practice. It fits into the broader Wiremold raceway product family as a power-carrying module, allowing installers to run circuits cleanly along finished surfaces without exposed conduit. This module is intended for installations where aesthetics, accessibility, and NEC-compliant surface wiring solutions are all required in a single assembly.

Key Features

• 48-inch module length supports extended wall runs with a single unit
• Surface-mount design eliminates the need for in-wall rough-in work
• 50.5-inch overall assembly length accommodates standard commercial bay spacing
• Compact 4.5-inch by 4.5-inch cross-section fits flush against walls and partitions
• Lightweight at 4.65 pounds for single-tech handling during installation

Compatibility

Designed as an OEM-style replacement and standard component within the Wiremold raceway power module product line for surface-mount electrical distribution assemblies.

Installation Notes

Installation of this raceway power module should be performed by a licensed electrician in accordance with NEC Article 386 governing surface metal raceways. De-energize all circuits at the panel before mounting or connecting the module. Secure the raceway base to the wall substrate using appropriate fasteners for the surface material, then seat the module and snap or screw the cover into place per manufacturer instructions. Do not exceed the raceway's listed conductor fill capacity when routing wiring through the assembly.

Technical Specifications

• Length: 50.5 inches
• Width: 4.5 inches
• Height: 4.5 inches
• Weight: 4.65 pounds
• UPC: 78677607611

Standard Information

• Brand: WIREMOLD
• Manufacturer Part Number: PM48T
