Winters PWL2832 Pressure Gauge 3000 Psi 2.5 in Dial Brass

Product Description

The WINTERS PWL2832 is a brass case cylinder pressure gauge designed for monitoring gas cylinder and compressed fluid system pressures in industrial, HVAC, and mechanical service applications. The gauge features a 2.5-inch dial diameter with a display range of 0 to 4000 psi and a maximum operating pressure rating of 3000 psi. The 1/4-inch NPT bottom-mount connection allows direct installation into standard cylinder valve outlets and manifold ports. A polycarbonate lens protects the dial face from impact and moisture. Accuracy is rated at 3 percent of full scale, which meets typical field service requirements for cylinder pressure monitoring. The unit weighs 0.35 pounds.

The PWL2832 suits residential and commercial service work wherever compressed gas cylinder pressures must be monitored at the point of use. Typical applications include refrigerant cylinder monitoring, compressed air systems, nitrogen service, and general mechanical gas distribution panels. The bottom-mount NPT connection makes it a practical replacement or addition on vertical cylinder valve assemblies and manifold headers. HVAC technicians, plumbers, and industrial gas service professionals are the primary installers of this gauge type.

Key Features

• 3000 psi maximum operating pressure with a 0 to 4000 psi display range
• 2.5-inch dial diameter for clear readability in tight service spaces
• 1/4-inch NPT bottom-mount connection fits standard cylinder valve outlets
• Brass case construction for durability in field service environments
• Polycarbonate lens resists impact and moisture on the job site
• 3 percent full-scale accuracy meets general field service requirements

Compatibility

Designed as an OEM-style replacement or service addition for compressed gas cylinder assemblies and manifold systems equipped with 1/4-inch NPT bottom-mount gauge ports rated to 3000 psi or higher.

Installation Notes

Installation should be performed by a qualified HVAC technician, plumber, or industrial gas service professional. Depressurize and isolate the cylinder or system before removing or installing any pressure gauge. Apply an appropriate thread sealant or PTFE tape to the NPT threads per system requirements and applicable codes. Do not exceed the 3000 psi maximum operating pressure rating of this gauge.
