WINTERS PFQ807R1 - 2.5 Inch Pressure Gauge

Product Description

The WINTERS PFQ807R1 is a 2.5 inch pressure gauge suitable for measuring pressure up to 300 PSI. This gauge has a 1/4 inch NPT lower connection that simplifies installation. Its design includes a stainless steel enclosure and a Bourdon tube as the sensing element. The glycerin-filled case enhances resistance to vibration and pulsation, making it reliable for use in harsh conditions. It enables efficient monitoring of pressure in various applications including hydraulic systems, compressors, and pipelines.

• Features a 2.5 inch dial for easy reading
• Measures pressure up to 300 PSI
• Constructed with corrosion-resistant stainless steel

Product Highlights

The gauge is ideal for use in both industrial and commercial environments, where accurate pressure readings are crucial.

Product Information

Standard Information

• Item Number: PFQ807R1
• Brand: Winters Instruments

Technical Specifications

• Enclosure: Stainless Steel
• End Connection: 1/4 inch NPT
• Filled: Glycerin
• Mounting: Lower
• Pressure: 300 PSI
• Sensing Element: Bourdon Tube
• Size: 2.5 inches
