WINTERS PFQ803R1 Pressure Gauge

Product Description

The WINTERS PFQ803R1 pressure gauge provides accurate pressure readings across various applications. With a dial size of two point five inches and a durable stainless steel case, this gauge is engineered for reliability. It is filled with glycerin, which helps reduce vibration and pulsation, making it suitable for both hydraulic and pneumatic systems.

• Pressure gauge with a two point five inch dial and stainless steel case
• Glycerin filled for enhanced vibration resistance
• Measures up to sixty PSI

Product Highlights

Precision-engineered for maximum accuracy and durability, the gauge works in a wide range of environments and conditions.

Product Information

Standard Information

• Brand: Winters Instruments
• MPN: PFQ803R1

Technical Specifications

• Dial Size: 2.5 inches (63mm)
• Pressure Range: 60 PSI
• Connection: 7/16-20 SAE, lower mount
• End Connection: 1/4 inch NPT
• Mounting: Lower
• Case Material: AISI 304 stainless steel
• Enclosure: Stainless steel
• Fill Liquid: Glycerin
• Sensing Element: Bourdon tube
• Socket: Brass with restricted orifice
• Pointer: Aluminum, anodized black
• Accuracy: ±1.5% of full scale
• Enclosure Rating: IP65
• Ambient/Process Temperature: Dry: -40°F to 200°F; Glycerin Filled: -4°F to 150°F
• Over-Pressure Limit: 25% for pressures up to 1,450 PSI; 15% for pressures over 1,500 PSI
• Socket Gasket: Buna N for two-piece internal socket seal
• Lens: Polycarbonate
