WINTERS PFQ802R1 Pressure Gauge

Product Description

The WINTERS PFQ802R1 is a liquid-filled pressure gauge suitable for both hydraulic and pneumatic uses. This gauge has a stainless steel casing and a polycarbonate lens, ensuring durability. The gauge reads pressure in dual units: psi and bar, displayed clearly on a white aluminum dial. It meets ASME B40.1 standards and is CRN registered.

• Liquid-filled AISI 304 stainless steel case
• Brass socket, bourdon tube, and movement
• 7/16-20 SAE lower mount connection

Product Highlights

This pressure gauge is reliable and provides accurate readings for various applications.

Product Information

Standard Information

• Brand: WINTERS
• MPN: PFQ802R1

Technical Specifications

• Dial: 2.5 inches (63mm) white aluminum with black and red markings
• Case: AISI 304 stainless steel
• Lens: Polycarbonate
• Socket: Brass with restricted orifice
• Connection: 7/16-20 SAE, lower mount
• Fill Liquid: Glycerin
• Bourdon Tube: C-shaped for pressures up to 600 psi, spiral for pressures over 1000 psi
• Accuracy: ±1.5% of full scale
