WINCO 24018-016 WL18000VE-03/E Portable Generator

Product Description

The WINCO WL18000VE-03/E is a portable generator built for roofing and spray foam applications. This unit includes a Briggs & Stratton Vanguard engine and has a fuel tank capacity of fifteen gallons. The generator features a YourGen meter, providing real-time data on hours, RPM, voltage, and frequency. It also has low oil protection, ensuring engine safety by shutting down if oil levels are too low. Each unit undergoes a 100% load test prior to shipping.

• Powered by a Briggs & Stratton Vanguard engine.
• Includes a YourGen meter for performance monitoring.
• Low oil protection system prevents engine damage.

Product Highlights

This generator is ideal for standby and intermittent use in various applications, providing reliable power where needed.

Product Information

Standard Information

• Manufacturer: Winco
• MPN: 24018-016

Technical Specifications

• Power Type: Conventional
• Frequency: 60 Hz
• Voltage: 120/240 VAC
• Voltage VDC: 12
• Phase AC: 1PH
• Cooling System: Air Cooled
• Fuel Type: Gasoline
• Fuel Tank Run Time: 6 hrs
• Housing: Open
• Application: Standby / Intermittent
• Starting Watts: 19,000
• Running Watts: 17,000
• Running Amps: 79.1/70.8
• Voltage Regulation: Capacitor
• 120 Volt Receptacles: (2) NEMA 5-20R (GFCI) Duplex
• 120/240 Volt Receptacle: (1) NEMA 14-60 60A (1) L14-30 30A (GFCI)
• 240 Volt Receptacle: (1) L6-30R 30 Amp (GFCI)
• Engine Brand: Briggs
• Emissions: EPA Prime
• Dimensions: 43 x 28.85 x 28.85 inches
• Weight: 504 lbs
• Unit Warranty: 3 Years Commercial
• Assembled In: USA
