Williams Comfort Products PL-530C 45 Degree Pilot Tip

Product Description

The WILLIAMS COMFORT PRODUCTS PL-530C is a 45-degree pilot tip with a 0.120-inch orifice diameter, designed for precise gas pilot flame delivery in heating appliances. Pilot tips control the angle and flow of the pilot flame, ensuring reliable ignition of the main burner. This tip is a small but critical component in the pilot assembly and is typically serviced by licensed gas appliance technicians or HVAC professionals during burner maintenance or ignition troubleshooting. At 0.03 pounds, it is a compact, single-unit replacement part suited for gas heating equipment service calls.

This pilot tip is used in gas-fired heating appliances where a 45-degree flame angle is specified by the original equipment design. It is appropriate for residential and light commercial applications. Technicians typically install or replace this part when the pilot orifice is fouled, corroded, or damaged, or when restoring a pilot assembly to factory configuration. No specific compatible model numbers were provided in the product data; refer to your equipment service manual to confirm fitment before installation.

Key Features

• 45-degree tip angle directs pilot flame at the correct trajectory for proper burner ignition
• 0.120-inch orifice diameter for precise gas metering at the pilot
• Lightweight single-unit replacement part at 0.03 pounds
• OEM-style pilot tip format for straightforward drop-in service

Compatibility

Designed as an OEM-style replacement pilot tip for gas-fired heating appliances requiring a 45-degree tip angle with a 0.120-inch orifice diameter. Confirm compatibility with your specific appliance model using the equipment service manual before ordering.

Installation Notes

Installation should be performed by a licensed HVAC technician or qualified gas appliance service professional. Shut off the gas supply and allow the appliance to cool completely before accessing the pilot assembly. Handle the orifice carefully to avoid any deformation that could alter gas flow. Follow all applicable local gas codes and manufacturer service instructions when reassembling the pilot assembly.

Technical Specifications

• Tip Angle: 45 degrees
• Orifice Diameter: 0.120 inches
• Weight: 0.03 pounds
• Unit of Measure: Each
• UPC: 662459270429

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: PL-530C
