Williams Comfort Products JHW17-692 Deep Impact Socket

Product Description

The WILLIAMS COMFORT PRODUCTS JHW17-692 is a deep impact socket designed for heavy-duty fastener removal and installation in demanding trade environments. Built on a 1 inch drive, this socket features a 2 7/8 inch opening and an overall length of 4 7/8 inches, making it suited for reaching deep-set fasteners that standard-depth sockets cannot access. The socket is specially heat treated for impact use, providing the structural integrity required for high-torque applications. SUPERTORQUE lobular openings deliver greater turning power while reducing the risk of fastener deformation. Electricians, pipefitters, ironworkers, and mechanical contractors will find this tool relevant to heavy structural and mechanical assembly work.

This deep impact socket is built for use with both pneumatic and electric impact wrenches, covering the range of power tools found on commercial and industrial job sites. The SAE sizing and 6-point fastener engagement make it appropriate for structural bolting, equipment installation, and maintenance tasks where oversized fasteners are common. Its deep-well profile is particularly useful when working with threaded rod, extended bolt shanks, or recessed fastener applications in mechanical and electrical installations.

Key Features

• SUPERTORQUE lobular openings reduce fastener rounding under high torque
• Designed for maximum engagement on 6-point fasteners
• Compatible with pneumatic and electric impact wrenches
• Specially heat treated for impact use to ensure long service life and safety
• Deep-well profile at 4 7/8 inches OAL for access to recessed or extended fasteners
• 1 inch drive for use with heavy-duty impact tools

Compatibility

Designed for use with 1 inch drive pneumatic and electric impact wrenches in SAE applications requiring a 2 7/8 inch deep impact socket.

Installation Notes

This socket should be installed on a properly rated 1 inch drive impact wrench before use. Inspect the socket for cracks or deformation before each use and remove from service if damage is found. Do not use impact sockets with hand ratchets or torque wrenches, as they are not designed for that loading profile. Ensure the drive retainer or pin-and-o-ring retention system is secured before applying torque.

Technical Specifications

• Drive Size: 1 inch
• Opening Size: 2 7/8 inches
• Overall Length (OAL): 4 7/8 inches
• Point Configuration: 6 point
• Fastener Standard: SAE
• Socket Type: Deep Impact
• Weight: 8.59 pounds
• UOM: Each

Standard Information

• Brand: WILLIAMS COMFORT PRODUCTS
• Manufacturer Part Number: JHW17-692
