Wilkerson M18-02-BK00B Coalescing Filter 1/4 Port

Product Description

The WILKERSON M18-02-BK00B is a coalescing filter designed to remove oil aerosols, water droplets, and fine particulates from compressed air lines. Coalescing filtration works by forcing air through a media element that causes small droplets to merge into larger ones, which then drain away from the airstream. This unit features a 1/4 inch port size and compact dimensions, making it suitable for point-of-use installation in tight pneumatic assemblies. It weighs 0.71 pounds and measures 8.36 inches in height with a 2.36 inch by 2.36 inch footprint. Industrial maintenance technicians and automation specialists are the primary installers.

This coalescing filter is intended for use in compressed air systems where clean, dry air is required at the point of use. Typical applications include pneumatic tools, instrumentation lines, spray equipment, and automated machinery. The compact port size makes it well suited for light-duty and medium-duty industrial circuits where space and clean-air quality are both priorities. It is packaged and sold as a single unit.

Key Features

• Coalescing filter element removes oil aerosols and moisture from compressed air
• 1/4 inch port size fits standard pneumatic line connections
• Compact profile at 8.36 inches tall and 2.36 inches wide for space-constrained installations
• Lightweight at 0.71 pounds for easy inline mounting
• Single-unit packaging for individual replacement or system additions

Compatibility

Designed as an OEM-style replacement coalescing filter for compressed air systems equipped with 1/4 inch ported filter housings in light to medium industrial service.

Installation Notes

Installation should be performed by a qualified industrial maintenance technician or pneumatic systems specialist. Depressurize and lock out the compressed air supply completely before removing or installing any inline filter component. Verify that the port thread type and size match the existing line fittings before tightening connections. Do not exceed the rated pressure or flow specifications for the housing this filter element is paired with.
