Wilkerson D08-02-FLG0B Frl 28 Scfm 250 Psi 1/4 Npt

Product Description

The WILKERSON D08-02-FLG0B is a miniature 2-piece FRL combination unit that integrates a filter, regulator, and lubricator into a single inline assembly for compressed air systems. Rated to 250 psi maximum supply pressure and 28 SCFM flow capacity, this unit conditions compressed air by removing particulates down to 5 microns, regulating line pressure, and delivering metered lubrication to downstream pneumatic tools and actuators. The aluminum body and bowl construction keeps weight low at 1.43 pounds. A pressure gauge is included and mounts to the 1/4-inch gauge port. Installation is typically performed by industrial maintenance technicians, automation specialists, or plumbers working on compressed air distribution lines.

This FRL unit is designed for miniature-footprint installations where space is limited, such as small pneumatic control panels, point-of-use tool drops, and light-duty automation equipment. The 1/4 NPT port size suits smaller-bore compressed air lines common in workshop and light industrial environments. The modular connection design allows the unit to integrate with other Series 08 components. A manual drain on the filter bowl allows scheduled condensate removal as part of routine air system maintenance. Operating temperature range is -13 degrees F to 150 degrees F, making it suitable for most indoor industrial and shop environments.

Key Features

• 2-piece filter/regulator-lubricator combination in a single miniature assembly
• 28 SCFM flow rate with 250 psi maximum supply pressure
• 5-micron filtration rating removes fine particulates from compressed air supply
• Aluminum body and bowl construction for lightweight durability
• Includes pressure gauge and brackets; modular connection supports Series 08 expansion
• Manual drain for scheduled condensate removal; operating range -13 degrees F to 150 degrees F

Compatibility

Designed as an OEM-style replacement and modular component for Series 08 compressed air treatment systems using 1/4 NPT connections. Modular connection design supports integration with other Series 08 FRL components.

Installation Notes

Shut off and depressurize the compressed air supply line completely before installation or service. This unit should be installed by a qualified maintenance technician or pipefitter familiar with compressed air system plumbing and applicable safety codes. Mount the unit vertically with the bowls facing downward to ensure proper condensate collection and lubricator function. Verify that downstream flow direction matches the port markings on the body before finalizing connections.
