Wilkerson C28-06-FKG0B Frl 110 Scfm 150 Psi 3/4 Npt

Product Description

The WILKERSON C28-06-FKG0B is a three-piece FRL combination unit that integrates a filter, regulator, and lubricator into a single inline assembly for compressed air systems. It handles flows up to 110 SCFM at a maximum supply pressure of 150 psi. The unit ships with a pressure gauge and mounts through modular connections, making it a practical choice for industrial and commercial pneumatic circuits. The aluminum body resists corrosion in demanding shop environments, while the polycarbonate bowl provides a clear view of bowl contents during service. Licensed mechanical contractors and industrial maintenance technicians are the typical installers.

This FRL unit fits 3/4 NPT compressed air lines in a wide range of applications including manufacturing, process equipment, and automated assembly systems. The manual drain on the filter bowl makes it well suited for installations where regular condensate removal is part of a scheduled maintenance routine. The included pressure gauge and bracket hardware support quick integration into existing air preparation stations without sourcing additional hardware. It is rated for operating temperatures from -13 degrees F to 125 degrees F.

Key Features

• Three-piece filter-regulator-lubricator configuration in a single modular unit
• 110 SCFM flow capacity with 150 psi maximum supply pressure
• 3/4 NPT end connections for direct inline installation
• 5-micron filter element removes particulate from the air supply
• Polycarbonate bowl with bowl guard for safe, visible fluid monitoring
• Pressure gauge and mounting brackets included
• Manual drain on filter bowl for scheduled condensate removal

Compatibility

Designed as an OEM-style inline FRL replacement for 3/4 NPT compressed air preparation systems requiring combined filtration, pressure regulation, and lubrication in a standard three-piece modular configuration.

Installation Notes

Installation is performed by licensed mechanical or pneumatic system technicians. Depressurize and lockout the compressed air supply completely before removing or installing any FRL component. Verify that upstream supply pressure does not exceed 150 psi and that line flow requirements fall within the 110 SCFM rating. Follow applicable OSHA compressed air safety guidelines and local mechanical codes when servicing air preparation equipment.
