Wilkerson B28-06-FL00B Frl Filter Regulator 3/4 Npt

Product Description

The WILKERSON B28-06-FL00B is a single-piece filter/regulator combination unit designed for compressed air system preparation. It filters particulate down to 5 microns while simultaneously regulating downstream pressure, delivering up to 235 SCFM through a 3/4 NPT port. The aluminum body and aluminum bowl keep weight low at 1.87 pounds. A built-in sight glass allows technicians to monitor bowl fluid levels at a glance. The manual drain gives service personnel direct control over condensate removal. This unit is suited for installation by industrial maintenance technicians, pipefitters, and pneumatic system specialists.

The B28-06-FL00B is intended for compressed air distribution systems in light industrial, commercial, and manufacturing environments. It installs at point-of-use or at the inlet of pneumatic equipment requiring clean, regulated air. The 3/4 NPT end connections accommodate standard threaded pipe and fittings. With a maximum supply pressure rating of 250 psi and an operating temperature range of -13 degrees F to 150 degrees F, this unit fits a wide range of service conditions. The modular connection feature supports integration into multi-unit FRL assemblies within the Wilkerson Series 28 product family.

Key Features

• 235 SCFM flow capacity through 3/4 NPT ports
• 5-micron filtration rating removes fine particulate from compressed air supply
• 250 psi maximum supply pressure rating
• Aluminum body and bowl construction for reduced weight
• Integrated sight glass for visual condensate level monitoring
• Manual drain for controlled condensate removal
• Modular connection supports multi-stage FRL assembly configurations

Compatibility

Designed as an OEM-style replacement or new-installation filter/regulator combination for compressed air systems using 3/4 NPT threaded connections within the Wilkerson Series 28 modular FRL platform.

Installation Notes

Installation should be performed by a qualified pipefitter or pneumatic systems technician. Depressurize and lock out the compressed air supply before installing or servicing this unit. Thread connections should be sealed with appropriate thread sealant per the system requirements and local codes. Mount the unit vertically with the bowl oriented downward to ensure proper condensate collection and drainage.
