Wilkerson B28-06-FK00B Frl Filter Regulator 3/4 Npt

Product Description

The WILKERSON B28-06-FK00B is a single-piece filter/regulator combination unit designed for compressed air systems requiring reliable particulate removal and downstream pressure control in a compact, inline package. Built on the Series 28 platform with an aluminum body and polycarbonate bowl, it delivers up to 235 SCFM at a maximum supply pressure of 150 psi through a 3/4 NPT port. The 5-micron filtration rating captures fine particulate and water aerosols before they reach downstream tooling, valves, or pneumatic actuators. A manual drain and bowl guard are included. This unit is installed by industrial maintenance technicians, pipefitters, and automation system integrators on compressed air distribution lines.

The B28-06-FK00B suits a wide range of industrial and commercial compressed air applications where a single inline unit must handle both filtration and pressure regulation. Typical installations include manufacturing lines, assembly stations, pneumatic control panels, and general-purpose shop air systems. The 3/4 NPT end connections accommodate standard iron or brass pipe fittings, and the modular connection design allows the unit to be joined with other Series 28 components where expanded FRL functionality is needed. Operating temperature range spans -13 degrees F to 125 degrees F, making it suitable for most indoor industrial environments.

Key Features

• Single-piece filter/regulator configuration reduces plumbing complexity and installation time
• 235 SCFM flow capacity handles high-demand compressed air circuits
• 5-micron bowl filtration removes fine particulate and entrained moisture
• 150 psi maximum supply pressure rating suits standard industrial compressed air supply lines
• Modular connection design is compatible with other Series 28 FRL components
• Bowl guard and manual drain included; polycarbonate bowl allows visual monitoring of condensate level

Compatibility

Designed as an OEM-style inline filter/regulator for compressed air systems using 3/4 NPT connections; modular connection feature supports integration with other Wilkerson Series 28 FRL components.

Installation Notes

Installation is performed by qualified pipefitters or maintenance technicians following applicable compressed air system procedures. Depressurize and lock out the air supply before installing or servicing this unit. Mount with the bowl oriented downward to allow condensate to collect at the drain. Confirm all NPT thread connections are properly sealed with thread tape or pipe compound rated for compressed air service before pressurizing the system.
