Wiegmann N412202008C Enclosure 20 in H x 20 in W x 8 in D

Product Description

The WIEGMANN N412202008C enclosure is designed to house and protect electrical and electronic components in harsh environments. Constructed of carbon steel with a gray ANSI 61 polyester powder finish, this wall-mountable enclosure features a hinged cover with a 1/4 turn latch. It meets NEMA 3R, 4, and 12 standards and has an IP rating of 66.

• Constructed of carbon steel with polyester powder coating
• Features a seamless polyurethane poured in place gasket
• Designed with mounting holes for easy installation

Product Highlights

This Wiegmann enclosure protects electrical components from dirt, dust, oil, and water. It features continuously plasma welded seams and a 1/4-turn semi-flush oil-tight latch.

Product Information

Standard Information

• Brand: WIEGMANN
• Manufacturer Part Number: N412202008C
• Country of Origin: United States

Technical Specifications

• Depth: 8 in
• Width: 20 in
• Height: 20 in
• Finish: ANSI 61 Polyester Powder
• Gasket: Seamless Polyurethane Poured in Place
• Series: N412-C
• Features: Mounting Holes
• Material: Carbon Steel
• Mounting: Wall
• IP Rating: 66
• Standards: cULus
• Metal Gauge: 14 ga
• NEMA Rating: 3R, 4, 12
• Product Type: Enclosure
• Basic Material: Metallic
• Closure Method: 1/4 Turn Latch
• Solid / Clear Cover: Solid
• Enclosure Cover Type: Hinged
• Usable Opening Depth: 7.88 in
• Enclosure NEMA Rating: 12, 3R, 4
• Material of Enclosure: Carbon Steel
• Metallic / Non-Metallic: Metallic
• Nominal Enclosure Width: 20 in
• Enclosure Cover Features: 1/4 Turn Semiflush Latch
• Knockouts / No Knockouts: No Knockouts
• Type: 1-Door
• Capacity: 3200 cu-in
• Mounting Type: Wall
