Weldbend 020-180-000 Long Radius Pipe Elbow 18 in SCH 40/STD

Product Description

The Weldbend 020-180-000 is a long radius pipe elbow fitting made of carbon steel. This fitting features a nominal size of eighteen inches and adheres to SCH 40/STD schedule ratings. Designed for use in pipe systems, it provides reliable connections for changing directions in piping layouts.

• Long radius design for smoother flow
• Butt welded end style for secure connections
• Ideal for various piping applications

Product Highlights

This elbow fitting allows for a 45-degree angle turn in pipelines, reducing the risk of turbulence and pressure loss.

Product Information

Standard Information

• Brand: Weldbend
• MPN: 020-180-000

Technical Specifications

• Dimensions: 17-1/4 in ID x 18 in OD
• End Style: Butt Welded
• Fitting/Connector Type: 45 deg Elbow
• Material: Carbon Steel
• Nominal Size: 18 in
• Schedule Rating: SCH 40/STD
• Thickness: 3/4 in
• Type: Long Radius
