Weidmuller 7940100338 Cir brkr thrm 1a 24vdc sld swch

Product Description

The Weidmuller 7940100338 is a circuit breaker thermal 1A AC 24 V DC slide switch designed for DIN rail mounting. It ensures selective disconnection of 24VDC load systems. The ESX10-T responds faster to overload or short-circuit conditions than the switch-mode power supply through active current limitation.

• Circuit Breaker Thermal 1A AC 24 V DC Slide Switch DIN Rail
• Manual ON/OFF button (S1)
• Clear status and failure indication through LED, status output SF or Si contact F

Product Highlights

The Weidmuller circuit breaker is ideal for industrial applications, providing reliable circuit protection with a compact design.

Product Information

Standard Information

• Brand: Weidmuller
• Manufacturer Part Number: 7940100338

Technical Specifications

• Category: Circuit Protection
• Sub Category: Circuit Breakers
• Current Rating (Amps): 1A
• Manufacturer: Weidmcller
• Voltage Rating - DC: 24 V
• Series: ESX10-T
• Actuator Type: Slide Switch
• Number of Poles: 1
• Part Status: Active
• Illumination: Green, Orange, Red
• Mounting Type: DIN Rail
• Approval Agency: ATEX, CE, CSA C22.2 No 14, CSA C22.2 No 142, CSA C22.2 No 213, UL1604, UL508, UL2367, VDE
• Breaker Type: Thermal
• RoHS Status: ROHS3 Compliant
• ECCN: EAR99
• Moisture Sensitivity Level (MSL): 1 (Unlimited)
• REACH Status: REACH Unaffected
• Trip Time: 3
• Supply Voltage: 24
• hazardous: false
• Product Range: ESX10-T Series
• Load Current Max: 1
• Current Rating: 1
• Circuit Breaker Mounting: DIN Rail
• Brand: Weidmcller
• Voltage Rating - AC: 24 V
