Weidmuller 7917030000 Motor Connection Terminal Block 24A 500V

Product Description

The WEIDMULLER 7917030000 is a multi-level motor connection terminal block designed for feed-through and protective earth (PE) wiring applications in industrial control panels and motor starter assemblies. Built on a screw connection system, it accommodates up to 2.5 mm2 wire and is rated for 24 amps and 500 volts. The four-level design consolidates seven connections into a compact footprint, reducing panel wiring complexity. Constructed from Wemid thermoplastic material with a V-0 flame rating, it meets industrial safety standards for enclosed electrical assemblies. Licensed electricians and panel builders typically install this component.

This terminal block is suited for industrial and commercial electrical panel applications where motor circuits require organized multi-level termination. The four-level configuration allows feed-through and PE conductors to be routed and terminated at a single rail position, streamlining wiring in motor control centers, variable frequency drive enclosures, and similar assemblies. The dark beige housing conforms to standard industrial color conventions for easy identification on the DIN rail.

Key Features

• Multi-level, 4-level design with 7 total connection points in a single block
• Screw termination for secure, vibration-resistant conductor retention
• Rated 24 A and 500 V for motor circuit feed-through and PE applications
• Accepts up to 2.5 mm2 wire cross-section
• V-0 flame-rated Wemid thermoplastic housing
• Mounts on TS 35 (35 mm) DIN rail for standard panel integration

Compatibility

Designed for installation on TS 35 (35 mm) DIN rail systems as an OEM-style multi-level motor connection terminal block for industrial control panel and motor starter wiring.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC or local electrical code requirements. De-energize and lockout/tagout the panel before installing or servicing terminal blocks. Use a calibrated torque screwdriver appropriate for screw terminal blocks to avoid over-tightening and conductor damage. Verify conductor insulation is stripped to the correct length before seating in the terminal to ensure full contact.

Technical Specifications

• Wire Cross-Section: 2.5 mm2
• Current Rating: 24 A
• Voltage Rating: 500 V
• Number of Connections: 7
• Number of Levels: 4
• Connection Type: Screw
• Mounting: TS 35 DIN Rail
• Housing Material: Wemid Thermoplastic
• Flame Rating: V-0
• Housing Color: Dark Beige

Standard Information

• Brand: WEIDMULLER
• Manufacturer Part Number: 7917030000
