Weidmuller 2478150000 mcb 489 2P C 10A acdc

Product Description

The Weidmuller 2478150000 is a miniature circuit breaker with 2 poles and a 10 A nominal current. It is designed for AC/DC voltage types. This circuit breaker is suitable for DIN rail mounting and provides reliable circuit protection in various applications.

• Number of poles: 2
• Nominal current: 10 A
• Mounting Type: DIN rail

Product Highlights

Miniature circuit breaker with 2 poles, 10A, AC/DC voltage, and DIN rail mounting.

Product Information

Standard Information

• Brand: Weidmuller
• Manufacturer Part Number: 2478150000

Technical Specifications

• Version: Miniature circuit breaker, Number of poles: 2, 10 A, white
• Order No.: 2478150000
• Type: MCB 489 2P C 10A ACDC
• GTIN (EAN): 4050118491845
• Depth: 60.3 mm
• Depth (inches): 2.374 inch
• Height: 116 mm
• Height (inches): 4.567 inch
• Width: 35.3 mm
• Width (inches): 1.39 inch
• Net weight: 27.75 g
• Ambient temperature: -35 °C…70 °C
• Humidity: 40 °C / 95 % rel. humidity, no condensation
• Voltage type: AC/DC
• Rated AC voltage: 480,277 V
• Rated DC voltage: 125 V
• Nominal current: 10 A
• Interrupting capacity: 10,000 A
• Number of poles: 2
• Type of mounting: DIN rail
• Type of fixing: Rail mounting
• Vibration: according to IEC 60068-2-6
• Shock: according to IEC 60068-2-27
• Colour: white
• ETIM 8.0: EC000042
• ETIM 9.0: EC000042
• ETIM 10.0: EC000042
• ECLASS 14.0: 27-14-19-01
• ECLASS 15.0: 27-14-19-01
• Category: Circuit Protection
• Circuit Breakers: Circuit Breakers
• Voltage Rating - AC: 480 V
• Manufacturer: Weidmüller
• Voltage Rating - DC: 125 V
• Series: MCB 489
• Actuator Type: Lever
• Packaging: Bulk
• Part Status: Obsolete
• Illumination: None
• Approval Agency: CE, CSA C22.2 No 5, CSA C22.2 No 235, TUV, UL489, VDE
• Breaker Type: Thermal Magnetic
• Base Product Number: BR2C1
• Current Rating (Amps): 10A
• RoHS Status: ROHS3 Compliant
• ECCN: EAR99
• Moisture Sensitivity Level (MSL): 1 (Unlimited)
• HTSUS: 8536.20.0020
• REACH Status: REACH Unaffected
• Brand: Weidmuller
• Current Type: AC
• Interruption Type: Thermal Circuit Breaker
• Maximum Amperage: 125 A
• Model: BR2C10UC
• MPN: 2478150000, BR2C10UC
