Weidmuller Weidmuller 1127410000 tos 24VDC 230VAC1A
Weidmuller Weidmuller 1127410000 tos 24VDC 230VAC1A

Weidmuller 1127410000 tos 24VDC 230VAC1A

Brand: Weidmuller
SKU: 1127410000
Availability: In Stock

Ships same day if ordered by 12 pm
$44.66
$44.66
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Weidmuller 1127410000 TOS 24VDC 230VAC1A is a TERMSERIES solid-state relay with a rated control voltage of 24 V DC and a rated switching voltage of 24...240 V AC. It features a continuous current of 1 A and screw connections. This relay is suitable for industrial applications and DIN rail mounting.

  • Rated control voltage: 24 V DC
  • Rated switching voltage: 24...240 V AC
  • Continuous current: 1 A

Product Highlights

Solid-state relay with 24 V DC control voltage and 24...240 V AC switching voltage.

Product Information

Standard Information

  • Brand: Weidmuller
  • Manufacturer Part Number: 1127410000
  • Country of Origin: China
Technical Specifications
Version
TERMSERIES, Solid-state relay, Rated control voltage: 24 V DC ±20 % , Rated switching voltage: 24...240 V AC, Continuous current: 1 A, Screw connection
Order No.
1127410000
Type
TOS 24VDC 230VAC1A
GTIN (EAN)
4032248908967
Depth
87.8 mm
Depth (inches)
3.457 inch
Height
89.6 mm
Height (inches)
3.528 inch
Width
6.4 mm
Width (inches)
0.252 inch
Storage temperature
-40 °C...70 °C
Ambient temperature
-20 °C…60 °C
Humidity
5-95% relative humidity, Tu = 40°C, without condensation
MTTF
1,120 a
RoHS Compliance Status
Compliant with exemption
RoHS Exemption (if applicable/known)
7a, 7cI
REACH SVHC
Lead 7439-92-1
SCIP
9e2cbc49-76d9-4611-b8ec-5b4f549a0aa9
Ambient temperature (operational), max.
60 °C
Output current derating (ohmic)
1 A @ 25 °C 0.3 A @ 60 °C
Connection cross-section AWG, min.
AWG 26
Connection cross-section AWG, max.
AWG 14
Type of conductor
rigid copper conductor flexible copper conductor
Tightening torque, max.
0.4 Nm
Pollution severity level
2
Rated control voltage
24 V DC ±20 %
Nominal control current
11.5 mA DC (±10 %)
Power rating
280 mW
Status indicator
Green LED
Protective circuit
Free-wheeling diode
Reverse polarity protection
Input frequency
Coil voltage of the replacement relay deviating from the rated control voltage
No
Coil voltage of the replacement relay
24 V DC
Rated switching voltage
24...240 V AC
Continuous current
1 A
Rated switching current
1 A
Inrush current
15 A / 10 ms
Switch-on delay
≤ 12 ms
Switch-off delay
≤ 12 ms
Voltage drop at max. load
≤ 1.6 V
Leakage current
<1.5 mA
Min. switching current
20 mA
Short-circuit-proof
No
Protective circuit, load side
RC element
Contact type
1 NO contact (Triac (zero-cross switch))
Output voltage frequency range
50 / 60 Hz
max. switching frequency (DC control voltage)
3 Hz
Mounting rail
TS 35
Test button available
No
Colour
black
UL94 flammability rating component
Component: Housing UL94 flammability rating: V-0 Component: Retaining clip UL94 flammability rating: V-0
Rated voltage
300 V
Pollution severity
2
Surge voltage category
III
Clearance and creepage distances for control side - load side
≥ 5.5 mm
Dielectric strength for control side - load side
2.5 kV eff
Dielectric strength to mounting rail
4 kV eff / 1 Min.
Impulse withstand voltage
6 kV (1.2/50 µs)
Protection degree
IP20
Certificate No. (DNV)
TAA00001E5
Certificate no. (cULus)
E141197
Wire connection method
Screw connection
Stripping length, rated connection
8 mm
Clamping range, rated connection
1.5 mm²
Clamping range, min.
0.14 mm²
Clamping range, max.
2.5 mm²
Wire connection cross section AWG, min.
AWG 26
Wire connection cross section AWG, max.
AWG 14
Wire cross-section, solid, min.
0.14 mm²
Wire cross-section, solid, max.
2.5 mm²
Wire cross-section, solid, min. (AWG)
AWG 26
Wire cross-section, solid, max. (AWG)
AWG 14
Wire connection cross section, finely stranded, min.
0.14 mm²
Wire connection cross section, finely stranded, max.
2.5 mm²
Wire cross-section, finely stranded, min. (AWG)
AWG 26
Wire cross-section, finely stranded, max. (AWG)
AWG 14
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.
0.25 mm²
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.
2.5 mm²
Conductor cross-section, flexible, AEH (DIN 46228-1), min.
0.25 mm²
Conductor cross-section, flexible, AEH (DIN 46228-1), max.
2.5 mm²
Wire connection cross section, finely stranded, two clampable wires, min.
0.5 mm²
Wire cross-section, finely stranded, two clampable wires, max.
1 mm²
Blade size
size PH0
ETIM 8.0
EC001504
ETIM 9.0
EC001504
ETIM 10.0
EC001504
ECLASS 14.0
27-37-16-04
ECLASS 15.0
27-37-16-04
Brand
Weidmüller
MPN
1127410000, TOS 24VDC 230VAC1A
Model
Tos
Current Type
DC
Product Type
Solid State Relays
Coil Voltage
21-30 V
Maximum Amperage
1a
Application
Industrial
Contact Material
Plastic
Rated Current
1-15 a
Suitable For
Interior
Montageart
DIN Rail, Snaps, Insert/-switchable
Contact Configuration
none Specified
Mounting Type
DIN Rail
Relay Type
Photo-Coupled Relay (Photorelay)
Circuit
SPST-NO (1 Form A)
Output Type
AC, Zero Cross
Voltage - Input
24VDC
Voltage - Load
24 V ~ 240 V
Load Current
1 A
Termination Style
Screw Terminal
Operating Temperature
-20°C ~ 60°C
Package / Case
Module
Supplier Device Package
-
Approval Agency
CE, cULus, DNV, UKCA
Grade
-
Qualification
-
Base Product Number
112741
Relay Mounting
Din Rail
Relay Connection Type
Screw Connection
Coil Voltage Rating
24 VDC
Component
Solid State Relay
Manufacturer
Weidmuller
Relay Indication
Green LED
Relay Input Amperage
1 Amp
Enclosure Type
IP20
Temperature Rating
-20 to 60 deg C
Terminal Type
Screw
Dimensions
89.6 mm H x 6.4 mm W x 87.8 mm D
Contact Form
1NO 1 Form A
