Weg SSW050010T2246TPZ Soft-Starter 220-460 V

Product Description

The WEG SSW050010T2246TPZ soft starters are fitted with micro processors designed to ensure high performance during starts and stops of induction motors. These electronic starters accelerate, decelerate, and protect three-phase induction motors by controlling the voltage applied to the motor. They are compact, optimizing space in electrical panels and incorporating all protections for the driven motor.

• Currents: 3 to 85 A
• Voltage: 220 to 575 V
• Control with DSP

Product Highlights

WEG Soft-Starters ensure the highest performance during starts and stops of induction motors. They extend the lifespan of the motor and mechanical devices by eliminating mechanical shocks.

Product Information

Standard Information

• Brand: WEG
• Manufacturer Part Number: SSW050010T2246TPZ
• Country of Origin: United States

Technical Specifications

• Rated current: 10 A
• Power supply: 220-460 V
• Enclosure: IP00
• Frame: 1
• Amp Rating: 10 Amp
• Display/No Display: With Display
• Horsepower: See Spec
• Phase: Three Phase
• Series: SSW05
• Options: Built-in Bypass
• Soft Starter Type: Combination Starter
• Brand: WEG
• Manufacturer: WEG
• Part Number: SSW050010T2246TPZ
