Webstone H-82672W 1/2 inch FIP x Press Full Port T-Valve

Product Description

The WEBSTONE H-82672W is a 1/2 inch FIP x Press Full Port T-Valve designed for efficient installation and system operation. This forged brass valve is ideal for creating branch connections and shut-offs in confined spaces, replacing a tee, nipple, and ball valve. It is suitable for use with water, oil, and glycol mixtures in residential and commercial plumbing and heating systems, featuring a full port design and brass construction.

• Full Port design with 1/2 inch FIP x Press connection.
• Constructed from brass, ensuring durability and lead-free compliance.
• Replaces three components, simplifying installations and reducing potential leak paths.

Product Highlights

Ideal for branch connections and shut-offs in tight locations, featuring a reversible handle and adjustable packing gland.

Product Information

Standard Information

• Brand: WEBSTONE
• Manufacturer Part Number: H-82672W
• Country of Origin: Imported

Technical Specifications

• Nominal Size: 1/2 inch
• Body Material: Brass
• Lead Free: Yes
• Port Type: Full Port
• Connection Type: FIP ValvexPress Run
• Actuator Type: Stem
• Ball Material: Brass
• Media: Glycol/Oil/Water
• Orifice Size: 1/2 inch
• Pressure Rating: 250 psi CWP
• Series: Pro-Pal H-x267W Series
• Softgoods Material: EPDM/PTFE
• Temperature Rating: 250 deg F
• Top to Inlet Center: 1.58 inch
• Trim Material: PTFE/Brass
• Product Type: Threaded Ball Valve
• Collection: Pro-Connect, Pro-Pal
• Includes: Integrated Tee Fitting, Adjustable Packing Gland, Reversible Handle
