Warner Electric 5392-170-007 FB-650 56 ft-lb Static Torque 90 DC Voltage

Product Description

The Warner Electric 5392-170-007 is an electric brake designed for mechanical power transmission. This product features a permanent magnet brake type and operates with a voltage rating of ninety DC. It delivers a nominal static torque of fifty-six foot-pounds, making it suitable for various industrial applications.

• Permanent magnet design for efficient operation
• Compatible with through shaft mounting
• UL standards compliant

Product Highlights

This brake is ideal for applications requiring reliable stopping power and control.

Product Information

Standard Information

• Brand: Warner Electric
• MPN: 5392-170-007

Technical Specifications

• Bore Diameter: 2.281 inches
• Brake Outside Diameter: 6.578 inches
• Maximum Dynamic Torque Capacity: 56 ft-lbs
• Overall Length: 3.765 inches
• Voltage Rating: 90 V DC
• Nominal Static Torque: 56 ft-lbs
• Mounting Type: Through Shaft
• Standards Met: UL
