Walter Surface Technologies 15M044 Turbo Backing Pad

Product Description

The WALTER SURFACE TECHNOLOGIES 15M044 is a threaded turbo backing pad designed to mount abrasive discs on angle grinders and surface preparation tools. Built from plastic with medium flexibility, it accepts a standard 5/8-11 threaded spindle and is rated to a maximum of 13,300 RPM. The medium-flex construction allows the disc to conform slightly to curved or uneven workpiece surfaces, improving contact and cut consistency. A clamping nut is included. This backing pad is suited for professional metalworking, fabrication, and surface conditioning applications where consistent disc seating and reliable high-speed operation are required.

The 15M044 is intended for use with WALTER SURFACE TECHNOLOGIES COOLCUT XX and TRACUT cutting and grinding disc lines. It is appropriate for use on angle grinders in metal fabrication shops, structural steel work, and industrial maintenance settings. The 5/8-11 thread is the standard spindle size found on most 4.5-inch to 5-inch angle grinders used in trade and industrial environments. The medium-flexibility rating makes it a general-purpose choice across flat and mildly contoured stock.

Key Features

• 5/8-11 threaded mount for compatibility with standard angle grinder spindles
• Rated to 13,300 RPM maximum operating speed
• Medium-flexibility plastic construction conforms to slightly uneven surfaces
• Turbo backing pad profile supports consistent disc contact during cutting and grinding
• Includes clamping nut for secure disc retention
• Sold as a single unit with no minimum order above one

Compatibility

Designed for use with WALTER SURFACE TECHNOLOGIES COOLCUT XX and TRACUT disc lines. The 5/8-11 threaded mount fits most standard 4.5-inch to 5-inch angle grinders equipped with that spindle thread. Verify spindle thread and disc diameter before installation.

Installation Notes

Installation should be performed by a qualified operator familiar with angle grinder tooling and applicable ANSI B11 or OSHA abrasive wheel safety requirements. Disconnect and de-energize the grinder before mounting or removing the backing pad. Thread the pad fully onto the spindle by hand, then secure the abrasive disc with the included clamping nut using the appropriate spanner wrench. Never exceed the 13,300 RPM maximum speed rating of the pad.
